Motor:
Brushless motor on board
Lighting:
2x1,4W Dimmable and dinamic spot leds (2700 to 6500°K)
Control panel:
Remote control
App
Voice assistant
Filter:
Anodized aluminum (5+1 layers)
Material:
Stainless Steel
Finishing:
Ceiling plate matte White painted
Ceramic domes white or black matte glazed
Installation:
For the installation create a false ceiling with a niche of 425mm x 915mm whose minimum
height to be reached is 200 mm
PRODUCT | DIM. | MOTOR | IDENTIFIER | EEI | |||
---|---|---|---|---|---|---|---|
SUPERNOVA Brh | 930x440 | on board | C976093RA1374681 | A++ | ENERGY LABEL | TECH FICHE | Drawing |
SUPERNOVA 4V | 930x440 | on board | C976093RA1244681 | B | ENERGY LABEL | TECH FICHE | Drawing |
SUPERNOVA EM | 930x440 | SEM1 | C976093RA1294681 | A | ENERGY LABEL | TECH FICHE | Drawing |
SUPERNOVA EM | 930x440 | SEM2 | C976093RA1154681 | B | ENERGY LABEL | TECH FICHE | Drawing |
