Motor on board
Lighting:
2X4W Led spot (SL 909 85cm)
4x4W Led spot (SL 909 140cm)
Control Panel:
Chromed 4 speeds push-button+light switch+timer
Grease filter:
Commercial style baffle filters AISI304 with oil collector
Material:
Stainless steel AISI430
Installation:
Cut Out:
Create a niche in the cabinet for
825x410mm (SL 909 85cm version)
1365x410mm (SL 909 140cm version)
PRODUCT | DIM. | MOTOR | IDENTIFIER | EEI | |||
---|---|---|---|---|---|---|---|
SL 909 | 856 | on board | G909086PB1282648 | A | ENERGY LABEL | TECH FICHE | Drawing |
SL 909 | 1400 | on board | G909140PB1282648 | A | ENERGY LABEL | TECH FICHE | Drawing |
